基本資料

型號編碼

0170215772

型號全稱

Limited Edition American Standard Telecaster

Channel Bound, Rosewood Fingerboard, Dakota Red

系列

Special Edition

顏色

Sonic Blue

琴身

Body Material

Alder

Body Finish

Gloss Urethane

Body Shape

Telecaster

琴頸

Neck Material

Maple

Neck Finish

Hand-Rubbed Oil

Neck Shap

Modern "C"

Scale Length

25.5" (648 mm)

Fingerboard

Channel-Bound Rosewood

Fingerboard Radius

9.5"-14" Compound Radius (241 mm-355.6 mm)

Number of Frets

21

Fret Size

Medium Jumbo

String Nut

Synthetic Bone

Nut Width

1.685" (42.8 mm)

Position Inlays

White Dot

Truss Rods

Bi-Flex

Neck Plate

4-Bolt

電路系統(tǒng)

BridgePickup

Custom Shop Single-Coil Broadcaster

Neck Pickup

Custom Shop "Twisted" Single-Coil Tele

Controls:

Master Volume, Master No-Load Tone Control

Pickup Switching

3-Position Blade: Position

1. Bridge Pickup, Position

2. Bridge and Neck Pickups, Position

3. Neck Pickup

Pickup Configuration

SS

硬件

Bridge:

6-Saddle American Standard Strings-Through-Body Tele with Bent Steel Saddles and Stamped Brass Plate

Hardware Finish

Nickel/Chrome

Tuning

Machines

Deluxe Staggered Cast/Sealed

Pickguard

3-Ply Parchment

Control Knobs

Knurled Flat-Top

Switch Tips

Barrel Style

其它

Strings

Fender USA 250L, NPS (.009-.042 Gauges)
